Geospatial Mapping of Community Level Electrification in Nigeria Using VIIRS Nighttime Light Data with Threshold Optimization and Ground Validation
DOI:
https://doi.org/10.63746/njtd.v23i3.4579Keywords:
Electrification planning, VIIRS Night-time Light, Geospatial analysis, Energy access, Sub-Saharan AfricaAbstract
Reliable and spatially detailed information on electricity access is essential for effective rural electrification planning in Nigeria; however, existing statistics are typically reported at aggregated administrative levels, thereby masking important community-scale disparities. This study develops a high-resolution, cluster-level electrification mapping framework for Nigeria using satellite-derived night-time light observations, integrated with a statistically optimized radiance threshold and field-based validation. The 2024 Visible Infrared Imaging Radiometer Suite (VIIRS) Day/Night Band (DNB) radiance data were processed and corrected for gas flaring using VIIRS Nightfire products, and were subsequently applied to 22,696 geospatially defined community clusters in Nigeria. Candidate radiance thresholds within the literature-supported range of 0.25-0.50 nW·cm?²·sr?¹ were systematically evaluated using a grid-search approach that maximized the F1-score, and electrification status was assigned through cluster-level sampling at the resulting optimal threshold. The classification was validated against a combined reference dataset comprising Rural Electrification Agency mini-grid records, field-verified unelectrified communities, and confirmed electrified sites, using confusion matrix-based performance measures. Classification performance was most balanced at a threshold of 0.35 nW·cm?²·sr?¹, giving a precision of 0.69, a recall of 0.86, and an F1-score of 0.77, with 79.45 percent of clusters classified as unelectrified. The study contributes an optimized threshold-selection framework, a Nigeria-specific gas-flare correction approach, and a high-resolution electrification dataset, supporting electrification planning and policy formulation.
References
Adelabu, A. S. and Olusola, A. (2021). Mapping built-up areas using Sentinel-2 imagery. IEEE International Geoscience and Remote Sensing Symposium (IGARSS), pp. 4484–4487.
Coesfeld, J., Kuester, T., Kuechly, H. and Kyba, C. (2020). Reducing variability in VIIRS night-time light data. Sensors, 20, pp. 1–20.
Doll, C. and Pachauri, S. (2010). Estimating rural populations without access to electricity in developing countries through night-time light satellite imagery. Energy Policy, 38, pp. 5661–5670.
Earth Observation Group (2024a). VIIRS Nighttime Light Data. Available at: https://eogdata.mines.edu/products/vnl/ (Accessed: 17 March 2026).
Earth Observation Group (2024b). VIIRS Nightfire Data. Available at: https://eogdata.mines.edu/products/vnf/ (Accessed: 17 March 2026).
Elvidge, C. D., Baugh, K., Zhizhin, M., Hsu, F. and Ghosh, T. (2017). VIIRS night-time lights. International Journal of Remote Sensing, 38, pp. 5860–5879.
Elvidge, C. D., Zhizhin, M., Ghosh, T., Hsu, F. and Taneja, J. (2021). Annual time series of global VIIRS night-time lights derived from monthly averages. Remote Sensing, 13, pp. 1–14.
Falchetta, G., Pachauri, S., Byers, E., Danylo, O. and Parkinson, S. (2019). Satellite-based electrification dataset for Sub-Saharan Africa. Scientific Data, 6, pp. 1–9.
Falchetta, G., Pachauri, S., Byers, E., Danylo, O. and Parkinson, S. C. (2020). Global distribution of access to electricity. One Earth, 2, pp. 364–379.
Gao, X., Wu, M., Niu, Z. and Chen, F. (2022). Global identification of electrified areas using VIIRS data. Remote Sensing, 14, pp. 1–15.
Husein, M., Moner-Girona, M., Falchetta, G., Stevanato, N., Fahl, F. and Szabó, S. (2024). Settlement clustering for electrification planning. Heliyon, 10, e27440.
IEA (2023). World Energy Outlook 2023. Available at: https://www.iea.org/reports/world-energy-outlook-2023 (Accessed: 17 March 2026).
IEA, IRENA, UNSD, World Bank and WHO (2024). Tracking SDG7: The Energy Progress Report 2024. Washington, DC: World Bank.
Khavari, B., Korkovelos, A., Sahlberg, A., Howells, M. and Fuso Nerini, F. (2021). Spatial electrification modelling. Scientific Data, 8, pp. 1–17.
Li, X., Zhou, Y., Zhao, M. and Zhao, X. (2020). Mapping global urban extent using night-time lights. Scientific Data, 7, pp. 1–12.
Min, B., Gaba, K. M., Sarr, O. F. and Agalassou, A. (2013). Detection of electrification using night-time lights. International Journal of Remote Sensing, 34, pp. 8118–8141.
Wang, Z., Roman, M., Kalb, V., Miller, S., Zhang, J. and Shrestha, R. (2021). Assessment of VIIRS night-time light variability. Remote Sensing of Environment, 263, 112557.
World Bank (2024). Methodology for determining gas flare volumes from satellite data. Washington, DC: World Bank.
Yuan, X., Jia, L., Menenti, M. and Chen, Q. (2019). Improved detection of built-up areas using night-time lights. Remote Sensing, 11, 3002.
Yuan, X., Jia, L., Menenti, M. and Jiang, M. (2022). Night-time light data for urban analysis. Big Earth Data, 6, pp. 603–632.
Zhizhin, M., Elvidge, C. D., Ghosh, T., Gleason, G. and Bazilian, M. (2026). Global gas flaring monitoring using VIIRS Nightfire. Remote Sensing, 18, 314.
